ABB REC650 User Manual

10.3.6.5 Settings
Table 190: LOCREM Non group settings (basic)
Name
Values (Range) Unit Step Default Description
ControlMode Internal LR-switch
External LR-switch
- - Internal LR-switch Control mode for internal/external LR-
switch
10.3.7 Local remote control LOCREMCTRL
10.3.7.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Local remote control LOCREMCTRL - -
10.3.7.2 Functionality
The signals from the local HMI or from an external local/remote switch are applied via
the function blocks LOCREM and LOCREMCTRL to the Bay control QCBAY
function block. A parameter in function block LOCREM is set to choose if the switch
signals are coming from the local HMI or from an external hardware switch connected
via binary inputs.
10.3.7.3 Function block
IEC09000074_1_en.vsd
LOCREMCTRL
^PSTO1
^PSTO2
^PSTO3
^PSTO4
^PSTO5
^PSTO6
^PSTO7
^PSTO8
^PSTO9
^PSTO10
^PSTO11
^PSTO12
^HMICTR1
^HMICTR2
^HMICTR3
^HMICTR4
^HMICTR5
^HMICTR6
^HMICTR7
^HMICTR8
^HMICTR9
^HMICTR10
^HMICTR11
^HMICTR12
IEC09000074 V1 EN
Figure 114: LOCREMCTRL function block
1MRK 511 287-UEN A Section 10
Control
245
Technical manual
