GUID-B8A3A04C-430D-4488-9F72-8529FAB0B17D V1 EN
Figure 241: Settings for CMMXU: 1
All input signals to IEC 60870-5-103 I103MEAS must be connected in application
configuration. Connect an input signals on IEC 60870-5-103 I103MEAS that is not
connected to the corresponding output on MMXU function, to outputs on the fixed
signal function block.
12.19.2 Function block
IEC10000287-1-en.vsd
I103MEAS
BLOCK
IL1
IL2
IL3
IN
UL1
UL2
UL3
UL1L2
UN
P
Q
F
IEC10000287 V1 EN
Figure 242: I103MEAS function block
Section 12 1MRK 511 287-UEN A
Monitoring
502
Technical manual
