Name Type Description
WFMASTER BOOLEAN Signal to Slave issued by Master for sequential
reclosing
COUNT3P1 INTEGER Counting the number of three-phase reclosing shot
1
COUNT3P2 INTEGER Counting the number of three-phase reclosing shot
2
COUNT3P3 INTEGER Counting the number of three-phase reclosing shot
3
COUNT3P4 INTEGER Counting the number of three-phase reclosing shot
4
COUNT3P5 INTEGER Counting the number of three-phase reclosing shot
5
COUNTAR INTEGER Counting total number of reclosing shots
10.2.5 Settings
Table 173: SMBRREC Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
External ctrl
On
-
- External ctrl Off / ExternalCtrl / On
t1 3Ph 0.000 - 60.000 s 0.001 6.000 Open time for shot 1, delayed reclosing
3ph
tReclaim 0.00 - 6000.00 s 0.01 60.00 Duration of the reclaim time
tSync 0.00 - 6000.00 s 0.01 30.00 Maximum wait time for synchrocheck OK
tTrip 0.000 - 60.000 s 0.001 0.200 Maximum trip pulse duration
tCBClosedMin 0.00 - 6000.00 s 0.01 5.00 Minimum time that CB must be closed
before new sequence allows
tUnsucCl 0.00 - 6000.00 s 0.01 30.00 Wait time for CB before indicating
Unsuccessful/Successful
Priority None
Low
High
-
- None Priority selection between adjacent
terminals None/Low/High
tWaitForMaster 0.00 - 6000.00 s 0.01 60.00 Maximum wait time for release from
Master
Section 10 1MRK 511 287-UEN A
Control
228
Technical manual
