6.7.5 Settings
Table 68: CCRBRF Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
FunctionMode Current
Contact
Current&Contact
-
- Current Detection principle for back-up trip
BuTripMode 2 out of 4
1 out of 3
1 out of 4
-
- 1 out of 3 Back-up trip mode
RetripMode Retrip Off
CB Pos Check
No CBPos Check
-
- Retrip Off Operation mode of re-trip logic
IP> 5 - 200 %IB 1 10 Operate phase current level in % of IBase
IN> 2 - 200 %IB 1 10 Operate residual current level in % of
IBase
t1 0.000 - 60.000 s 0.001 0.000 Time delay of re-trip
t2 0.000 - 60.000 s 0.001 0.150 Time delay of back-up trip
Table 69: CCRBRF Group settings (advanced)
Name
Values (Range) Unit Step Default Description
I>BlkCont 5 - 200 %IB 1 20 Current for blocking of CB contact
operation in % of IBase
Table 70: CCRBRF Non group settings (basic)
Name
Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
6.7.6 Monitored data
Table 71: CCRBRF Monitored data
Name
Type Values (Range) Unit Description
IL1 REAL - A Measured current in
phase L1
IL2 REAL - A Measured current in
phase L2
IL3 REAL - A Measured current in
phase L3
IN REAL - A Measured residual
current
Section 6 1MRK 511 287-UEN A
Current protection
130
Technical manual
