Section 13 Metering
13.1 Pulse counter PCGGIO
13.1.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Pulse counter PCGGIO
S00947 V1 EN
-
13.1.2 Functionality
Pulse counter (PCGGIO) function counts externally generated binary pulses, for
instance pulses coming from an external energy meter, for calculation of energy
consumption values. The pulses are captured by the BIO (binary input/output) module
and then read by the PCGGIO function. A scaled service value is available over the
station bus.
13.1.3 Function block
IEC09000335-2-en.vsd
PCGGIO
BLOCK
READ_VAL
BI_PULSE*
RS_CNT
INVALID
RESTART
BLOCKED
NEW_VAL
SCAL_VAL
IEC09000335 V2 EN
Figure 251: PCGGIO function block
13.1.4 Signals
Table 448: PCGGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
READ_VAL BOOLEAN 0 Initiates an additional pulse counter reading
BI_PULSE BOOLEAN 0 Connect binary input channel for metering
RS_CNT BOOLEAN 0 Resets pulse counter value
1MRK 511 287-UEN A Section 13
Metering
515
Technical manual
