Name Values (Range) Unit Step Default Description
URepTyp Cyclic
Dead band
Int deadband
-
- Dead band Reporting type
ULimHys 0.000 - 100.000 V 0.001 5.000 Hysteresis value in % of range and is
common for all limits
UAngDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
Table 365: VNMMXU Non group settings (advanced)
Name Values (Range) Unit Step Default Description
UZeroDb 0 - 100000 m% 1 500 Zero point clamping in 0,001% of range
UHiHiLim 0 - 2000000 V 1 96000 High High limit (physical value)
UHiLim 0 - 2000000 V 1 86000 High limit (physical value)
ULowLim 0 - 2000000 V 1 71000 Low limit (physical value)
ULowLowLim 0 - 2000000 V 1 66000 Low Low limit (physical value)
UMin 0 - 2000000 V 1 0 Minimum value
12.1.7.5 Monitored data
Table 366: VNMMXU Monitored data
Name
Type Values (Range) Unit Description
UL1 REAL - kV UL1 Amplitude,
magnitude of reported
value
UL1ANGL
REAL - deg UL1 Angle, magnitude of
reported value
UL2 REAL - kV UL2 Amplitude,
magnitude of reported
value
UL2ANGL
REAL - deg UL2 Angle, magnitude of
reported value
UL3 REAL - kV UL3 Amplitude,
magnitude of reported
value
UL3ANGL
REAL - deg UL3 Angle, magnitude of
reported value
12.1.8 Operation principle
12.1.8.1 Measurement supervision
The protection, control, and monitoring IEDs have functionality to measure and
further process information for currents and voltages obtained from the pre-
1MRK 511 287-UEN A Section 12
Monitoring
409
Technical manual
