ABB REC650 User Manual

11.8 Integer to boolean 16 conversion with logic node
representation IB16FCVB
11.8.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Integer to boolean 16 conversion with
logic node representation
IB16FCVB - -
11.8.2 Functionality
Integer to boolean conversion with logic node representation function IB16FCVB is
used to transform an integer to 16 binary (logic) signals.
IB16FCVB function can receive remote values over IEC61850 when the operator
position input PSTO is in position remote. The block input will freeze the output at the
last value.
11.8.3 Function block
IB16FCVB
BLOCK
PSTO
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
OUT16
IEC09000399-1-en.vsd
IEC09000399 V1 EN
Figure 194: IB16FCVB function block
11.8.4 Signals
Table 330: IB16FCVB Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
PSTO INTEGER 1 Operator place selection
Section 11 1MRK 511 287-UEN A
Logic
384
Technical manual
