ABB REC650 User Manual

15.2 Time synchronization
15.2.1 Functionality
The time synchronization source selector is used to select a common source of
absolute time for the IED when it is a part of a control and a protection system. This
makes it possible to compare event and disturbance data between all IEDs in a station
automation system.
Micro SCADA OPC server should not be used as a time
synchronization source.
15.2.2 Time synchronization TIMESYNCHGEN
15.2.2.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Time synchronization TIMESYNCHGE
N
- -
15.2.2.2 Settings
Table 491: TIMESYNCHGEN Non group settings (basic)
Name
Values (Range) Unit Step Default Description
CoarseSyncSrc Off
SNTP
DNP
IEC60870-5-103
-
- Off Coarse time synchronization source
FineSyncSource Off
SNTP
IRIG-B
-
- Off Fine time synchronization source
SyncMaster Off
SNTP-Server
- - Off Activate IED as synchronization master
15.2.3 Time synchronization via SNTP
15.2.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Time synchronization via SNTP SNTP - -
Section 15 1MRK 511 287-UEN A
Basic IED functions
550
Technical manual

ABB REC650 Specifications

General

Product Type	REC650
Voltage Supply	100-240 V AC
Input Voltage	24 - 240 V AC/DC
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3
Inputs	Binary inputs, analog inputs
Outputs	Binary outputs
Display	LCD
Mounting	Panel Mount
Protection Functions	Overcurrent, Earth Fault, Distance Protection
