Name Values (Range) Unit Step Default Description

U1HiHiLim 0 - 2000000 V 1 96000 High High limit (physical value)

U1HiLim 0 - 2000000 V 1 86000 High limit (physical value)

U1LowLim 0 - 2000000 V 1 71000 Low limit (physical value)

U1LowLowLim 0 - 2000000 V 1 66000 Low Low limit (physical value)

U1LimHys 0.000 - 100.000 % 0.001 5.000 Hysteresis value in % of range and is

common for all limits

U2ZeroDb 0 - 100000 m% 1 500 Zero point clamping

U2HiHiLim 0 - 2000000 V 1 96000 High High limit (physical value)

U2HiLim 0 - 2000000 V 1 86000 High limit (physical value)

U2LowLim 0 - 2000000 V 1 71000 Low limit (physical value)

U2LowLowLim 0 - 2000000 V 1 66000 Low Low limit (physical value)

12.1.6.5 Monitored data

Table 361: VMSQI Monitored data

Name Type Values (Range) Unit Description

3U0 REAL - kV 3U0 Amplitude

3U0ANGL REAL - deg 3U0 Angle

U1 REAL - kV U1 Amplitude

U1ANGL REAL - deg U1 Angle

U2 REAL - kV U2 Amplitude

U2ANGL REAL - deg U2 Angle

12.1.7 Phase-neutral voltage measurement VNMMXU

12.1.7.1 Identification

Function description

IEC 61850

identification

IEC 60617

identification

ANSI/IEEE C37.2

device number

Phase-neutral voltage measurement VNMMXU

SYMBOL-UU V1 EN

12.1.7.2 Function block

The available function blocks of an IED are depending on the actual hardware (TRM)

and the logic configuration made in PCM600.

1MRK 511 287-UEN A Section 12

Monitoring

407

Technical manual
