6.11.2.2 Function block
IEC08000506-2-en.vsd
GOPPDOP
I3P*
U3P*
BLOCK
BLKST1
BLKST2
TRIP
TRIP1
TRIP2
START
START1
START2
P
PPERCENT
Q
QPERCENT
IEC08000506 V2 EN
Figure 64: GOPPDOP function block
6.11.2.3 Signals
Table 91: GOPPDOP Input signals
Name Type Default Description
I3P GROUP
SIGNAL
- Three phase group signal for current inputs
U3P GROUP
SIGNAL
- Three phase group signal for voltage inputs
BLOCK BOOLEAN 0 Block of function
BLKST1 BOOLEAN 0 Block of step 1
BLKST2 BOOLEAN 0 Block of step 2
Table 92: GOPPDOP Output signals
Name
Type Description
TRIP BOOLEAN General trip signal
TRIP1 BOOLEAN Trip signal from stage 1
TRIP2 BOOLEAN Trip signal from stage 2
START BOOLEAN General start signal
START1 BOOLEAN Start signal from stage 1
START2 BOOLEAN Start signal from stage 2
P REAL Active Power
PPERCENT REAL Active power in % of calculated power base value
Q REAL Reactive power
QPERCENT REAL Reactive power in % of calculated power base
value
1MRK 511 287-UEN A Section 6
Current protection
145
Technical manual
