Name Values (Range) Unit Step Default Description
UnderTrigLe08 0 - 200 % 1 50 Under trigger level for analog channel 8 in
% of signal
OverTrigOp08 Off
On
- - Off Use over level trigger for analog channel 8
(on) or not (off)
OverTrigLe08 0 - 5000 % 1 200 Over trigger level for analog channel 8 in
% of signal
NomValue09 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 9
UnderTrigOp09 Off
On
- - Off Use under level trigger for analog channel
9 (on) or not (off)
UnderTrigLe09 0 - 200 % 1 50 Under trigger level for analog channel 9 in
% of signal
OverTrigOp09 Off
On
- - Off Use over level trigger for analog channel 9
(on) or not (off)
OverTrigLe09 0 - 5000 % 1 200 Over trigger level for analog channel 9 in
% of signal
NomValue10 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 10
UnderTrigOp10 Off
On
- - Off Use under level trigger for analog channel
10 (on) or not (off)
UnderTrigLe10 0 - 200 % 1 50 Under trigger level for analog channel 10
in % of signal
OverTrigOp10 Off
On
- - Off Use over level trigger for analog channel
10 (on) or not (off)
OverTrigLe10 0 - 5000 % 1 200 Over trigger level for analog channel 10 in
% of signal
12.4.4 Analog input signals A4RADR
12.4.4.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Analog input signals A4RADR - -
12.4.4.2 Function block
A4RADR
^INPUT31
^INPUT32
^INPUT33
^INPUT34
^INPUT35
^INPUT36
^INPUT37
^INPUT38
^INPUT39
^INPUT40
IEC09000350-1-en.vsd
IEC09000350 V1 EN
Figure 214: A4RADR function block, derived analog inputs
1MRK 511 287-UEN A Section 12
Monitoring
437
Technical manual
