6.9.8 Technical data
Table 84: CCRPLD technical data
Function
Range or value Accuracy
Operate value, current
asymmetry level
(0-100) % ± 1.0% of I
r
Reset ratio >95% -
Time delay (0.000-60.000) s ± 0.5% ± 25 ms
6.10 Broken conductor check BRCPTOC
6.10.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Broken conductor check BRCPTOC - 46
6.10.2 Functionality
Conventional protection functions can not detect the broken conductor condition.
Broken conductor check BRCPTOC function, consisting of continuous phase
selective current unsymmetrical check on the line where the IED is connected will
give alarm or trip at detecting broken conductors.
6.10.3 Function block
BRCPTOC
I3P*
BLOCK
TRIP
START
IEC09000277_1_en.vsd
IEC09000277 V1 EN
Figure 62: BRCPTOC function block
6.10.4 Signals
Table 85: BRCPTOC Input signals
Name
Type Default Description
I3P GROUP
SIGNAL
- Three phase group signal for current inputs
BLOCK BOOLEAN 0 Block of function
1MRK 511 287-UEN A Section 6
Current protection
141
Technical manual
