Name Values (Range) Unit Step Default Description
TrigLevel13 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 13
IndicationMa13 Hide
Show
- - Hide Indication mask for binary channel 13
TrigLevel14 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 14
IndicationMa14 Hide
Show
- - Hide Indication mask for binary channel 14
TrigLevel15 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 15
IndicationMa15 Hide
Show
- - Hide Indication mask for binary channel 15
TrigLevel16 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 16
IndicationMa16 Hide
Show
- - Hide Indication mask for binary channel 16
12.4.6 Operation principle
Disturbance report DRPRDRE is a common name for several functions to supply the
operator, analysis engineer, and so on, with sufficient information about events in the
system.
The functions included in the disturbance report are:
• Event list
• Indications
• Event recorder
• Trip value recorder
• Disturbance recorder
Figure 216 shows the relations between Disturbance Report, included functions and
function blocks. Event list , Event recorder and Indications uses information from the
binary input function blocks (BxRBDR). Trip value recorder uses analog information
from the analog input function blocks (AxRADR). Disturbance recorder DRPRDRE
acquires information from both AxRADR and BxRBDR.
Section 12 1MRK 511 287-UEN A
Monitoring
448
Technical manual
