Name of input Type Default Description Value when
activated
Value when
deactivated
IN10 BOOLEAN 0 Input 10 512 0
IN11 BOOLEAN 0 Input 11 1024 0
IN12 BOOLEAN 0 Input 12 2048 0
IN13 BOOLEAN 0 Input 13 4096 0
IN14 BOOLEAN 0 Input 14 8192 0
IN15 BOOLEAN 0 Input 15 16384 0
IN16 BOOLEAN 0 Input 16 32768 0
The sum of the numbers in column “Value when activated” when all INx (where
1≤x≤16) are active that is=1; is 65535. 65535 is the highest boolean value that can be
converted to an integer by the B16IFCVI function block.
11.7 Integer to boolean 16 conversion IB16A
11.7.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Integer to boolean 16 conversion IB16A - -
11.7.2 Functionality
Integer to boolean 16 conversion function IB16A is used to transform an integer into
a set of 16 binary (logical) signals.
11.7.3 Function block
IB16A
BLOCK
INP
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
OUT16
IEC09000036-1-en.vsd
IEC09000036 V1 EN
Figure 193: IB16A function block
1MRK 511 287-UEN A Section 11
Logic
381
Technical manual
