Name of input Type Default Description Value when
activated
Value when
deactivated
IN14 BOOLEAN 0 Input 14 8192 0
IN15 BOOLEAN 0 Input 15 16384 0
IN16 BOOLEAN 0 Input 16 32768 0
The sum of the numbers in column “Value when activated” when all INx (where
1≤x≤16) are active that is=1; is 65535. 65535 is the highest boolean value that can be
converted to an integer by the B16I function block.
11.6 Boolean 16 to integer conversion with logic node
representation B16IFCVI
11.6.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Boolean 16 to integer conversion with
logic node representation
B16IFCVI - -
11.6.2 Functionality
Boolean 16 to integer conversion with logic node representation function B16IFCVI
is used to transform a set of 16 binary (logical) signals into an integer. The block input
will freeze the output at the last value.
Section 11 1MRK 511 287-UEN A
Logic
378
Technical manual
