10.3.8 Select release SELGGIO
10.3.8.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Select release SELGGIO - -
10.3.8.2 Function block
SELGGIO
SELECT1
SELECT2
SELECT3
SELECT4
SELECT5
SELECT6
SELECT7
SELECT8
SELECT9
SELECT10
SELECT11
SELECT12
SELECT13
SELECT14
SELECT15
SELECT16
RESERVED
IEC09000084_1_en.vsd
IEC09000084 V1 EN
Figure 115: SELGGIO function block
10.3.8.3 Signals
Table 193: SELGGIO Input signals
Name
Type Default Description
SELECT1 BOOLEAN 0 Select signal of control 1
SELECT2 BOOLEAN 0 Select signal of control 2
SELECT3 BOOLEAN 0 Select signal of control 3
SELECT4 BOOLEAN 0 Select signal of control 4
SELECT5 BOOLEAN 0 Select signal of control 5
SELECT6 BOOLEAN 0 Select signal of control 6
SELECT7 BOOLEAN 0 Select signal of control 7
SELECT8 BOOLEAN 0 Select signal of control 8
SELECT9 BOOLEAN 0 Select signal of control 9
SELECT10 BOOLEAN 0 Select signal of control 10
SELECT11 BOOLEAN 0 Select signal of control 11
SELECT12 BOOLEAN 0 Select signal of control 12
SELECT13 BOOLEAN 0 Select signal of control 13
SELECT14 BOOLEAN 0 Select signal of control 14
SELECT15 BOOLEAN 0 Select signal of control 15
SELECT16 BOOLEAN 0 Select signal of control 16
1MRK 511 287-UEN A Section 10
Control
247
Technical manual
