GlobalBaseSel: Selects the global base value group used by the function to define
(IBase), (UBase) and (SBase).
12.13.6 Operation principle
The input signal must be connected to a range output of a measuring function block
(CVMMXN, CMMXU, VMMXU, VNMMXU, CMSQI, VMSQ or MVGGIO). The
function block converts the input integer value to five binary output signals according
to
table 405.
Table 405: Input integer value converted to binary output signals
Measured supervised
value is:
below low-low
limit
between low‐
low and low
limit
between low
and high limit
between high-
high and high
limit
above high-
high limit
Output:
LOWLOW High
LOW High
NORMAL High
HIGH High
HIGHHIGH High
12.14 Fault locator LMBRFLO
12.14.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Fault locator LMBRFLO - -
12.14.2 Functionality
The Fault locator LMBRFLO in the IED is an essential complement to other
monitoring functions, since it measures and indicates the distance to the fault with
great accuracy. It indicates the distance to fault in kilometers or miles as selected by
parameter setting.
The fault locator LMBRFLO function, supports kilometer and mile
for the line length unit. The fault distance will be presented with the
same unit as the line length and is mapped to IEC61850 -8-1
communication protocol, where the fault distance is supposed to be in
kilometer (km). Select the line length unit to kilometer for compliance
with IEC61850.
1MRK 511 287-UEN A Section 12
Monitoring
471
Technical manual
