12.1.3.2 Function block
The available function blocks of an IED are depending on the actual hardware (TRM)
and the logic configuration made in PCM600.
CMMXU
I3P IL1
IL1RANG
IL1ANGL
IL2
IL2RANG
IL2ANGL
IL3
IL3RANG
IL3ANGL
IEC08000225 V1 EN
Figure 198: CMMXU function block
12.1.3.3 Signals
Table 342: CMMXU Input signals
Name Type Default Description
I3P GROUP
SIGNAL
- Three phase group signal for current inputs
Table 343: CMMXU Output signals
Name
Type Description
IL1 REAL IL1 Amplitude
IL1RANG INTEGER IL1 Amplitude range
IL1ANGL REAL IL1 Angle
IL2 REAL IL2 Amplitude
IL2RANG INTEGER IL2 Amplitude range
IL2ANGL REAL IL2 Angle
IL3 REAL IL3 Amplitude
IL3RANG INTEGER IL3 Amplitude range
IL3ANGL REAL IL3 Angle
12.1.3.4 Settings
Table 344: CMMXU Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
ILDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
Table continues on next page
Section 12 1MRK 511 287-UEN A
Monitoring
398
Technical manual
