ABB REC650 User Manual

11.3.2.4 Pulse timer function block PULSTIMERQT
Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Pulse timer function block PULSTIMERQT - -
Functionality
Pulse timer function block (PULSETIMERQT) can be used, for example, for pulse
extensions or limiting of operation of outputs. The pulse timer has a settable length
and will also propagate quality and time.
When the input goes to 1 the output will be 1 for the time set by the time delay
parameter t. Then return to 0.
When the output changes value, the timestamp of the output signal is updated.
The supported “quality” state bits are propagated from the input each execution to the
output. A change of these bits will not lead to an updated timestamp on the output.
Function block
PULSETIMERQT
INPUT OUT
IEC09000304-1-en.vsd
IEC09000304 V1 EN
Figure 180: PULSETIMERQT function block
Signals
Table 295: PULSETIMERQT Input signals
Name
Type Default Description
INPUT BOOLEAN 0 Input signal
Table 296: PULSETIMERQT Output signals
Name
Type Description
OUT BOOLEAN Output signal
Settings
Table 297: PULSETIMERQT Non group settings (basic)
Name
Values (Range) Unit Step Default Description
t 0.000 - 90000.000 s 0.001 0.010 Pulse time length
Section 11 1MRK 511 287-UEN A
Logic
362
Technical manual
