Function block
INDCOMBSPQT
SP_IN*
TIME*
BLOCKED*
SUBST*
INVALID*
TEST*
SP_OUT
IEC09000306-1-en.vsd
IEC09000306 V1 EN
Figure 188: INDCOMBSPQT function block
Signals
Table 315: INDCOMBSPQT Input signals
Name Type Default Description
SP_IN BOOLEAN 0 Single point indication
TIME GROUP
SIGNAL
0 Timestamp
BLOCKED BOOLEAN 0 Blocked for update
SUBST BOOLEAN 0 Substitued
INVALID BOOLEAN 0 Invalid value
TEST BOOLEAN 0 Testmode
Table 316: INDCOMBSPQT Output signals
Name
Type Description
SP_OUT BOOLEAN Single point indication
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
11.3.2.12 Indication extractor single position function block INDEXTSPQT
Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Single indication signal extractor
function block
INDEXTSPQT - -
Functionality
Value part of single position input is copied to SI_OUT output.
1MRK 511 287-UEN A Section 11
Logic
371
Technical manual
