Table 407: LMBRFLO Output signals
Name Type Description
CALCMADE BOOLEAN Fault calculation made
FLT_X REAL Reactive distance to fault
BCD_80 BOOLEAN Distance in binary coded data, bit represents 80%
BCD_40 BOOLEAN Distance in binary coded data, bit represents 40%
BCD_20 BOOLEAN Distance in binary coded data, bit represents 20%
BCD_10 BOOLEAN Distance in binary coded data, bit represents 10%
BCD_8 BOOLEAN Distance in binary coded data, bit represents 8%
BCD_4 BOOLEAN Distance in binary coded data, bit represents 4%
BCD_2 BOOLEAN Distance in binary coded data, bit represents 2%
BCD_1 BOOLEAN Distance in binary coded data, bit represents 1%
12.14.5 Settings
Table 408: LMBRFLO Group settings (basic)
Name Values (Range) Unit Step Default Description
R1A 0.001 - 1500.000 ohm/p 0.001 2.000 Source resistance A (near end)
X1A 0.001 - 1500.000 ohm/p 0.001 12.000 Source reactance A (near end)
R1B 0.001 - 1500.000 ohm/p 0.001 2.000 Source resistance B (far end)
X1B 0.001 - 1500.000 ohm/p 0.001 12.000 Source reactance B (far end)
R1L 0.001 - 1500.000 ohm/p 0.001 2.000 Positive sequence line resistance
X1L 0.001 - 1500.000 ohm/p 0.001 12.500 Positive sequence line reactance
R0L 0.001 - 1500.000 ohm/p 0.001 8.750 Zero sequence line resistance
X0L 0.001 - 1500.000 ohm/p 0.001 50.000 Zero sequence line reactance
R0M 0.000 - 1500.000 ohm/p 0.001 0.000 Zero sequence mutual resistance
X0M 0.000 - 1500.000 ohm/p 0.001 0.000 Zero sequence mutual reactance
LineLengthUnit kilometer
miles
- - kilometer Line length unit
LineLength 0.0 - 10000.0 - 0.1 40.0 Length of line
Table 409: LMBRFLO Non group settings (basic)
Name
Values (Range) Unit Step Default Description
DrepChNoIL1 1 - 30 Ch 1 1 Recorder input number recording phase
current, IL1
DrepChNoIL2 1 - 30 Ch 1 2 Recorder input number recording phase
current, IL2
DrepChNoIL3 1 - 30 Ch 1 3 Recorder input number recording phase
current, IL3
DrepChNoIN 0 - 30 Ch 1 4 Recorder input number recording residual
current, IN
Table continues on next page
1MRK 511 287-UEN A Section 12
Monitoring
473
Technical manual
