Table 292: ORQT Output signals
Name Type Description
OUT BOOLEAN Output signal
NOUT BOOLEAN Inverted output signal
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
11.3.2.3 INVERTERQT function block
Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
INVERTERQT function block INVERTERQT - -
Function block
INVERTERQT
INPUT OUT
IEC09000299-1-en.vsd
IEC09000299 V1 EN
Figure 179: INVERTERQT function block
Signals
Table 293: INVERTERQT Input signals
Name
Type Default Description
INPUT BOOLEAN 0 Input signal
Table 294: INVERTERQT Output signals
Name
Type Description
OUT BOOLEAN Output signal
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
1MRK 511 287-UEN A Section 11
Logic
361
Technical manual
