ABB REC650 User Manual

12.20.4 Settings
Table 435: I103MEASUSR Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 25 Function type (1-255)
InfNo 1 - 255 - 1 1 Information number for measurands
(1-255)
MaxMeasur1 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
1
MaxMeasur2 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
2
MaxMeasur3 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
3
MaxMeasur4 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
4
MaxMeasur5 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
5
MaxMeasur6 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
6
MaxMeasur7 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
7
MaxMeasur8 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
8
MaxMeasur9 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on input
9
12.21 Function status auto-recloser for IEC 60870-5-103
I103AR
12.21.1 Functionality
I103AR is a function block with defined functions for autorecloser indications in
monitor direction. This block includes the FunctionType parameter, and the
information number parameter is defined for each output signal.
12.21.2 Function block
I103AR
BLOCK
16_ARACT
128_CBON
130_BLKD
IEC10000289-2-en.vsd
IEC10000289 V2 EN
Figure 244: I103AR function block
1MRK 511 287-UEN A Section 12
Monitoring
505
Technical manual
