10.4.8.3
Function block
DB_BUS_A
QA1_OP
QA1_CL
QB1_OP
QB1_CL
QB61_OP
QB61_CL
QC1_OP
QC1_CL
QC2_OP
QC2_CL
QC3_OP
QC3_CL
QC11_OP
QC11_CL
EXDU_ES
QB61_EX1
QB61_EX2
QB1_EX1
QB1_EX2
QA1CLREL
QA1CLITL
QB61REL
QB61ITL
QB1REL
QB1ITL
QC1REL
QC1ITL
QC2REL
QC2ITL
QB1OPTR
QB1CLTR
VPQB1TR
IEC09000077_1_en.vsd
IEC09000077 V1 EN
Figure 144:
DB_BUS_A function block
DB_BUS_B
QA2_OP
QA2_CL
QB2_OP
QB2_CL
QB62_OP
QB62_CL
QC4_OP
QC4_CL
QC5_OP
QC5_CL
QC3_OP
QC3_CL
QC21_OP
QC21_CL
EXDU_ES
QB62_EX1
QB62_EX2
QB2_EX1
QB2_EX2
QA2CLREL
QA2CLITL
QB62REL
QB62ITL
QB2REL
QB2ITL
QC4REL
QC4ITL
QC5REL
QC5ITL
QB2OPTR
QB2CLTR
VPQB2TR
IEC09000078_1_en.vsd
IEC09000078 V1 EN
Figure 145:
DB_BUS_B function block
DB_LINE
QA1_OP
QA1_CL
QA2_OP
QA2_CL
QB61_OP
QB61_CL
QC1_OP
QC1_CL
QC2_OP
QC2_CL
QB62_OP
QB62_CL
QC4_OP
QC4_CL
QC5_OP
QC5_CL
QB9_OP
QB9_CL
QC3_OP
QC3_CL
QC9_OP
QC9_CL
VOLT_OFF
VOLT_ON
QB9_EX1
QB9_EX2
QB9_EX3
QB9_EX4
QB9_EX5
QB9REL
QB9ITL
QC3REL
QC3ITL
QC9REL
QC9ITL
IEC09000082_1_en.vsd
IEC09000082 V1 EN
Figure 146:
DB_LINE function block
1MRK 511 287-UEN A
Section 10
Control
295
Technical manual
300
302
