Name Type Description
OUTPUT6 BOOLEAN Command output 6
OUTPUT7 BOOLEAN Command output 7
OUTPUT8 BOOLEAN Command output 8
10.12.4 Settings
Table 250: I103USRCMD Non group settings (basic)
Name Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
PulseMode Steady
Pulsed
- - Pulsed Pulse mode
PulseLength 0.200 - 60.000 s 0.001 0.400 Pulse length
InfNo_1 1 - 255 - 1 1 Information number for output 1 (1-255)
InfNo_2 1 - 255 - 1 2 Information number for output 2 (1-255)
InfNo_3 1 - 255 - 1 3 Information number for output 3 (1-255)
InfNo_4 1 - 255 - 1 4 Information number for output 4 (1-255)
InfNo_5 1 - 255 - 1 5 Information number for output 5 (1-255)
InfNo_6 1 - 255 - 1 6 Information number for output 6 (1-255)
InfNo_7 1 - 255 - 1 7 Information number for output 7 (1-255)
InfNo_8 1 - 255 - 1 8 Information number for output 8 (1-255)
10.13 Function commands generic for IEC 60870-5-103
I103GENCMD
10.13.1 Functionality
I103GENCMD is used for transmitting generic commands over IEC 60870-5-103.
The function has two outputs signals CMD_OFF and CMD_ON that can be used to
implement double-point command schemes.
The I103GENCMD component can be configured as either 2 pulsed ON/OFF or 2
steady ON/OFF outputs. The ON output is pulsed with a command with value 2, while
the OFF output is pulsed with a command value 1. If in steady mode is ON asserted
and OFF deasserted with command 2 and vice versa with command 1. The
I103GENCMD is retained, and a command in steady mode will be reissued on restart.
The standard does not define the use of values 0 and 3. However, when connected to
a switching device, these values are transmitted.
1MRK 511 287-UEN A Section 10
Control
337
Technical manual
