VPQB1
VPQB3
VPQB2
VPQB4
QB2_OP
QB1_OP
QB3_OP
QB1_OP
QB4_OP
VPQB1
QB1_CL
QB2_OP
VPQB1
1
1
QC1ITL
QC1REL
QC2REL
QC2ITL
en04000541.vsd
&
QB1OPTR
QB1CLTR
VPQB1TR
>1
QB1_OP
QB2_OP
1
QB12OPTR
QB12CLTR
&VPQB2
VPQB12TR
QB2_CL
VPQB2
QB2OPTR
QB2CLTR
VPQB2TR
IEC04000541 V1 EN
10.4.10.5 Signals
Table 223: AB_TRAFO Input signals
Name Type Default Description
QA1_OP BOOLEAN 0 QA1 is in open position
QA1_CL BOOLEAN 0 QA1 is in closed position
QB1_OP BOOLEAN 0 QB1 is in open position
QB1_CL BOOLEAN 0 QB1 is in closed position
QB2_OP BOOLEAN 0 QB2 is in open position
QB2_CL BOOLEAN 0 QB2 is in closed position
QC1_OP BOOLEAN 0 QC1 is in open position
QC1_CL BOOLEAN 0 QC1 is in closed position
QC2_OP BOOLEAN 0 QC2 is in open position
QC2_CL BOOLEAN 0 QC2 is in closed position
QB3_OP BOOLEAN 0 QB3 is in open position
QB3_CL BOOLEAN 0 QB3 is in closed position
QB4_OP BOOLEAN 0 QB4 is in open position
QB4_CL BOOLEAN 0 QB4 is in closed position
QC3_OP BOOLEAN 0 QC3 is in open position
QC3_CL BOOLEAN 0 QC3 is in closed position
QC11_OP BOOLEAN 0 QC11 on busbar WA1 is in open position
QC11_CL BOOLEAN 0 QC11 on busbar WA1 is in closed position
QC21_OP BOOLEAN 0 QC21 on busbar WA2 is in open position
QC21_CL BOOLEAN 0 QC21 on busbar WA2 is in closed position
BC_12_CL BOOLEAN 0 A bus coupler connection exists between busbar
WA1 and WA2
VP_BC_12 BOOLEAN 0 Status of the bus coupler apparatuses between
WA1 and WA2 are valid
EXDU_ES BOOLEAN 0 No transmission error from any bay containing
earthing switches
EXDU_BC BOOLEAN 0 No transmission error from any bus coupler bay
Table continues on next page
Section 10 1MRK 511 287-UEN A
Control
316
