5.4.3 Signals
Table 20: FNKEYMD1 Input signals
Name
Type Default Description
LEDCTL1 BOOLEAN 0 LED control input for function key
Table 21: FNKEYMD1 Output signals
Name Type Description
FKEYOUT1 BOOLEAN Output controlled by function key
5.4.4 Settings
Table 22: FNKEYMD1 Non group settings (basic)
Name Values (Range) Unit Step Default Description
Mode Off
Toggle
Pulsed
-
- Off Output operation mode
PulseTime 0.001 - 60.000 s 0.001 0.200 Pulse time for output controlled by
LCDFn1
LabelOn 0 - 18 - 1 LCD_FN1_ON Label for LED on state
LabelOff 0 - 18 - 1 LCD_FN1_OFF Label for LED off state
Table 23: FNKEYTY1 Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Type Off
Menu shortcut
Control
-
- Off Function key type
MenuShortcut Menu shortcut for
function key
1MRK 511 287-UEN A Section 5
Local Human-Machine-Interface LHMI
61
