6.11.3.3 Signals
Table 97: GUPPDUP Input signals
Name
Type Default Description
I3P GROUP
SIGNAL
- Three phase group signal for current inputs
U3P GROUP
SIGNAL
- Three phase group signal for voltage inputs
BLOCK BOOLEAN 0 Block of function
BLKST1 BOOLEAN 0 Block of step 1
BLKST2 BOOLEAN 0 Block of step 2
Table 98: GUPPDUP Output signals
Name Type Description
TRIP BOOLEAN General trip signal
TRIP1 BOOLEAN Trip signal from stage 1
TRIP2 BOOLEAN Trip signal from stage 2
START BOOLEAN General start signal
START1 BOOLEAN Start signal from stage 1
START2 BOOLEAN Start signal from stage 2
P REAL Active Power
PPERCENT REAL Active power in % of calculated power base value
Q REAL Reactive power
QPERCENT REAL Reactive power in % of calculated power base
value
6.11.3.4 Settings
Table 99: GUPPDUP Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
OpMode1 Off
UnderPower
- - UnderPower Operation mode 1
Power1 0.0 - 500.0 % 0.1 1.0 Power setting for stage 1 in % of
calculated power base value
Angle1 -180.0 - 180.0 Deg 0.1 0.0 Characteristic angle for stage 1
TripDelay1 0.010 - 6000.000 s 0.001 1.000 Trip delay for stage 1
OpMode2 Off
UnderPower
- - UnderPower Operation mode 2
Power2 0.0 - 500.0 % 0.1 1.0 Power setting for stage 2 in % of
calculated power base value
Angle2 -180.0 - 180.0 Deg 0.1 0.0 Characteristic angle for stage 2
TripDelay2 0.010 - 6000.000 s 0.001 1.000 Trip delay for stage 2
Section 6 1MRK 511 287-UEN A
Current protection
148
Technical manual
