Name Type Values (Range) Unit Description
OUT7 GROUP
SIGNAL
- - Output 7 status
OUT8 GROUP
SIGNAL
- - Output 8 status
OUT9 GROUP
SIGNAL
- - Output 9 status
OUT10 GROUP
SIGNAL
- - Output 10 status
OUT11 GROUP
SIGNAL
- - Output 11 status
OUT12 GROUP
SIGNAL
- - Output 12 status
OUT13 GROUP
SIGNAL
- - Output 13 status
OUT14 GROUP
SIGNAL
- - Output 14 status
OUT15 GROUP
SIGNAL
- - Output 15 status
OUT16 GROUP
SIGNAL
- - Output 16 status
OUTOR GROUP
SIGNAL
- - Output status logic OR
gate for input 1 to 16
12.11.7 Operation principle
Upon receiving signals at its inputs, IEC 61850 generic communication I/O functions
16 inputs (SP16GGIO) function will send the signals over IEC 61850-8-1 to the
equipment or system that requests this signals. To be able to get the signal, one must
use other tools, described in the Engineering manual and define which function block
in which equipment or system should receive this information.
There are also 16 output signals that show the input status for each input as well as an
OR type output combined for all 16 input signals. These output signals are handled in
PST.
12.12 IEC 61850 generic communication I/O functions
MVGGIO
12.12.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
IEC61850 generic communication I/O
functions
MVGGIO - -
1MRK 511 287-UEN A Section 12
Monitoring
467
Technical manual
