Table 309: Truth table for RSMEMORYQT function block
RESET SET OUT NOUT
0 0 Last
value
Inverted last
value
0 1 0 1
1 0 1 0
1 1 0 1
Function block
RSMEMORYQT
SET
RESET
OUT
NOUT
IEC09000302-1-en.vsd
IEC09000302 V1 EN
Figure 186: RSMEMORYQT function block
Signals
Table 310: RSMEMORYQT Input signals
Name
Type Default Description
SET BOOLEAN 0 Input signal to set
RESET BOOLEAN 0 Input signal to reset
Table 311: RSMEMORYQT Output signals
Name
Type Description
OUT BOOLEAN Output signal
NOUT BOOLEAN Inverted output signal
Settings
Table 312: RSMEMORYQT Group settings (basic)
Name
Values (Range) Unit Step Default Description
Memory Off
On
- - On Operating mode of the memory function
11.3.2.10 INVALIDQT function block
Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
INVALIDQT function block INVALIDQT - -
Section 11 1MRK 511 287-UEN A
Logic
368
Technical manual
