Signals
Table 281: AND Input signals
Name
Type Default Description
INPUT1 BOOLEAN 1 Input signal 1
INPUT2 BOOLEAN 1 Input signal 2
INPUT3 BOOLEAN 1 Input signal 3
INPUT4 BOOLEAN 1 Input signal 4
Table 282: AND Output signals
Name Type Description
OUT BOOLEAN Output signal
NOUT BOOLEAN Inverted output signal
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
11.3.1.10 Set-reset memory function block SRMEMORY
Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Set-reset memory function block SRMEMORY - -
Functionality
The Set-Reset function SRMEMORY is a flip-flop with memory that can set or reset
an output from two inputs respectively. Each SRMEMORY function block has two
outputs, where one is inverted. The memory setting controls if the flip-flop after a
power interruption will return the state it had before or if it will be reset. For a Set-
Reset flip-flop, SET input has higher priority over RESET input.
Table 283: Truth table for the Set-Reset (SRMEMORY) function block
SET
RESET OUT NOUT
1 0 1 0
0 1 0 1
1 1 1 0
0 0 0 1
1MRK 511 287-UEN A Section 11
Logic
357
Technical manual
