Name Values (Range) Unit Step Default Description
MaxNoStoreRec 10 - 100 - 1 100 Maximum number of stored disturbances
ZeroAngleRef 1 - 30 Ch 1 1 Trip value recorder, phasor reference
channel
OpModeTest Off
On
- - Off Operation mode during test mode
12.4.2.5 Monitored data
Table 380: DRPRDRE Monitored data
Name Type Values (Range) Unit Description
MemoryUsed INTEGER - % Memory usage (0-100%)
UnTrigStatCh1 BOOLEAN - - Under level trig for analog
channel 1 activated
OvTrigStatCh1 BOOLEAN - - Over level trig for analog
channel 1 activated
UnTrigStatCh2 BOOLEAN - - Under level trig for analog
channel 2 activated
OvTrigStatCh2 BOOLEAN - - Over level trig for analog
channel 2 activated
UnTrigStatCh3 BOOLEAN - - Under level trig for analog
channel 3 activated
OvTrigStatCh3 BOOLEAN - - Over level trig for analog
channel 3 activated
UnTrigStatCh4 BOOLEAN - - Under level trig for analog
channel 4 activated
OvTrigStatCh4 BOOLEAN - - Over level trig for analog
channel 4 activated
UnTrigStatCh5 BOOLEAN - - Under level trig for analog
channel 5 activated
OvTrigStatCh5 BOOLEAN - - Over level trig for analog
channel 5 activated
UnTrigStatCh6 BOOLEAN - - Under level trig for analog
channel 6 activated
OvTrigStatCh6 BOOLEAN - - Over level trig for analog
channel 6 activated
UnTrigStatCh7 BOOLEAN - - Under level trig for analog
channel 7 activated
OvTrigStatCh7 BOOLEAN - - Over level trig for analog
channel 7 activated
UnTrigStatCh8 BOOLEAN - - Under level trig for analog
channel 8 activated
OvTrigStatCh8 BOOLEAN - - Over level trig for analog
channel 8 activated
UnTrigStatCh9 BOOLEAN - - Under level trig for analog
channel 9 activated
OvTrigStatCh9 BOOLEAN - - Over level trig for analog
channel 9 activated
Table continues on next page
1MRK 511 287-UEN A Section 12
Monitoring
429
Technical manual
