11.4.5 Settings
The function does not have any settings available in Local HMI or Protection and
Control IED Manager (PCM600).
11.4.6 Operation principle
There are nine outputs from FXDSIGN function block:
• OFF is a boolean signal, fixed to OFF (boolean 0) value
• ON is a boolean signal, fixed to ON (boolean 1) value
• INTZERO is an integer number, fixed to integer value 0
• INTONE is an integer number, fixed to integer value 1
• INTALONE is an integer value FFFF (hex)
• REALZERO is a floating point real number, fixed to 0.0 value
• STRNULL is a string, fixed to an empty string (null) value
• ZEROSMPL is a channel index, fixed to 0 value
• GRP_OFF is a group signal, fixed to 0 value
11.5 Boolean 16 to integer conversion B16I
11.5.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Boolean 16 to integer conversion B16I - -
11.5.2 Functionality
Boolean 16 to integer conversion function B16I is used to transform a set of 16 binary
(logical) signals into an integer.
1MRK 511 287-UEN A Section 11
Logic
375
Technical manual
