Name Type Default Description
COUNTER5 BOOLEAN 0 Input for counter 5
COUNTER6 BOOLEAN 0 Input for counter 6
RESET BOOLEAN 0 Reset of function
Table 369: CNTGGIO Output signals
Name Type Description
VALUE1 INTEGER Output of counter 1
VALUE2 INTEGER Output of counter 2
VALUE3 INTEGER Output of counter 3
VALUE4 INTEGER Output of counter 4
VALUE5 INTEGER Output of counter 5
VALUE6 INTEGER Output of counter 6
12.2.5 Settings
Table 370: CNTGGIO Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
12.2.6 Monitored data
Table 371: CNTGGIO Monitored data
Name
Type Values (Range) Unit Description
VALUE1 INTEGER - - Output of counter 1
VALUE2 INTEGER - - Output of counter 2
VALUE3 INTEGER - - Output of counter 3
VALUE4 INTEGER - - Output of counter 4
VALUE5 INTEGER - - Output of counter 5
VALUE6 INTEGER - - Output of counter 6
12.2.7 Operation principle
Event counter (CNTGGIO) has six counter inputs. CNTGGIO stores how many times
each of the inputs has been activated. The counter memory for each of the six inputs
is updated, giving the total number of times the input has been activated, as soon as an
input is activated.
To not risk that the flash memory is worn out due to too many writings, a mechanism
for limiting the number of writings per time period is included in the product. This
Section 12 1MRK 511 287-UEN A
Monitoring
422
Technical manual
