Table 301: TIMERSETQT Output signals
Name Type Description
ON BOOLEAN Output signal, pick-up delayed
OFF BOOLEAN Output signal, drop-out delayed
Settings
Table 302: TIMERSETQT Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
t 0.000 - 90000.000 s 0.001 0.000 Delay for settable timer n
11.3.2.7 ANDQT function block
Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
ANDQT function block ANDQT - -
Functionality
ANDQT function is used to form general combinatory expressions with boolean
variables. ANDQT function block has four inputs and two outputs.
Default value on all four inputs are logical 1 which makes it possible for the user to just
use the required number of inputs and leave the rest un-connected. The output OUT
has a default value 0 initially, which will suppress one cycle pulse if the function has
been put in the wrong execution order.
Function block
ANDQT
INPUT1
INPUT2
INPUT3
INPUT4
OUT
NOUT
IEC09000297-1-en.vsd
IEC09000297 V1 EN
Figure 184: ANDQT function block
1MRK 511 287-UEN A Section 11
Logic
365
Technical manual
