Description and default valueParameter
This field functions only on the line keys with Extension set to Disabled.
Used to assign extended functions to a line key on the phone. The supported functions
are:
• Busy Lamp Field (BLF)
Example: fnc=blf;sub=BLF_List_URI@$PROXY;usr=user_ID@$PROXY
• BLF with Call Pickup
Example: fnc=blf+cp;sub=BLF_List_URI@$PROXY;usr=user_ID@$PROXY
• Speed Dial
Example: fnc=sd;usr=user_ID@$PROXY
• BLF with Speed Dial
Example: fnc=blf+sd;sub=BLF_List_URI@$PROXY;usr=user_ID@$PROXY
• BLF with Speed Dial and Call Pickup
Example: fnc=blf+sd+cp;sub=BLF_List_URI@$PROXY;usr=user_ID@$PROXY
Perform one of the following:
• In the phone configuration file with XML(cfg.xml), enter a string in this format:
<Extended_Function_1_>fnc=sd;ext=user_ID@$PROXY</Extended_Function_1_>
• On the phone web interface, specify the functions that apply to the line key.
Default: Empty
Extended Function
Configure a Speed Dial on a Line Key
You can configure speed dial on an idle line of a user phone. The user can then use that line key to speed-dial
a number. When you enable the speed dial on the line key, the user sees the speed-dial icon a name for the
speed dial line key. The user presses the line key to dial the assigned extension.
Before you begin
Access the phone administration web page. See Access the Phone Web Interface, on page 104.
Procedure
Step 1 Select Voice > Phone.
Step 2 Select a Line Key on which to configure speed-dial.
Step 3 Set the Extension field to Disabled to disable the extension.
You can also configure this parameter in the phone configuration file (cfg.xml). The parameter is line-specific.
Enter a string in this format:
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
149
Cisco IP Phone Configuration
Configure a Speed Dial on a Line Key
