Configure the SIP Proxy Server
Before you begin
Access the phone administration web page. See Access the Phone Web Interface, on page 104.
Procedure
Step 1 Select Voice > Ext(n), where n is an extension number.
Step 2 In the Proxy and Registration section, set the parameter values as described in the SIP Proxy and Registration
for Extension Parameters, on page 375 table.
Step 3 Click Submit All Changes.
SIP Proxy and Registration for Extension Parameters
The following table defines the function and usage of the parameters in the Proxy and Registration section
under the Ext(n) tab in the phone web interface. It also defines the syntax of the string that is added in the
phone configuration file with XML(cfg.xml) code to configure a parameter.
Table 76: SIP Proxy and Registration for Extension
DescriptionParameter
SIP proxy server and port number set by the service
provider for all outbound requests. For example:
192.168.2.100:6060.
• In the phone configuration file with
XML(cfg.xml), enter a string in this format:
<Proxy_1_
ua="na">64.101.154.134</Proxy_1_>
<RTP_Port_Max
ua="na">16482</RTP_Port_Max>
• In the phone web page, enter SIP proxy server
and port number.
When you need to refer to this proxy in another
setting, for example, the speed dial line key
configuration, use the $PROXY macro variable.
Default: The port number is optional. If you don't
specify a port, the default port 5060 is used for UDP,
and the default port 5061 is used for TLS.
Proxy
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
375
Cisco IP Phone Installation
Configure the SIP Proxy Server
