You can also configure the parameters in the phone configuration file with XML(cfg.xml) code. See VQM
SIP Publish Message Parameters, on page 282
Before you begin
Access the phone administration web page. See Access the Phone Web Interface, on page 104.
Procedure
Step 1 Select Voice > Ext(n), where (n) is the extension number.
Step 2 In SIP Settings, enter a value for the Voice Quality Report Address parameter. You can enter either a domain
name or an IP address.
You can also add a port number along with the domain name or an IP address for this parameter. If you do
not enter a port number, the value of the SIP UDP Port (5060) is used by default. If the collector server URL
parameter is blank, a SIP PUBLISH message is not sent out.
Step 3 Enter your report name for the Voice Quality Report Group parameter.
Your report name can't begin with a hyphen (-), semicolon (;), or a space.
Step 4 Enter an interval, in seconds, for the Voice Quality Report Interval parameter. Example: 20 for 20-second
interval reporting.
Step 5 Click Submit All Changes.
VQM SIP Publish Message Parameters
The following table defines the Voice Quality Metrics (VQM) SIP Publish Message parameters in the Sip
Settings section under Voice > Ext(n) tab in the phone web interface. It also defines the syntax of the string
that is added in the phone configuration file (cfg.xml) with XML code to configure a parameter.
Table 58: VQM SIP Publish Message Parameters
DescriptionParameter Name
Allows you to enter one of the following options:
• Domain Name
• IP address
• The SIP UDP port number along with the domain
name
In the phone XML configuration file (cfg.xml), enter
a string in this format:
<Voice_Quality_Report_Address_1_
ua="na">fake_vq_collector</Voice_Quality_Report_Address_1_>
Default parameter = empty (no report)
Default SIP UDP Port = 5060
Voice Quality Report Address
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
282
Cisco IP Phone Configuration
VQM SIP Publish Message Parameters
