4 Individual remote controls
PC-LH3(A/B)
TCGB0106 rev.0 - 12/2014
178
4.4.4.3 Setting method
NOTE
To adjust the air ow angle, refer to the installation and operation manual of indoor unit.
Temperature setting
Point the transmitter towards the receiver kit and press “TEMP.” switch to set the temperature.
By pressing “
”, the temperature is increased by 1 ºC.
By pressing “
”, the temperature is decreased by 1 ºC.
COOL
°C
Me
The set temperature is set to 28
ºC in the cooling operation
NOTE
• The temperature is not displayed during the stoppage. In the case that the temperature is set during the stoppage, the temperature
indication is turned ON temporally. It is automatically turned OFF after setting.
• The temperature can be set for each operation mode.
• The setting temperature is available from 17 ºC to 30 ºC by the wireless remote control switch. However, for indoor unit which setting
temperature range is 19~30 ºC, the temperature settings of 17 ºC and 18 ºC are not available.
Fan Speed
Point the transmitter towards the receiver kit and press “FAN” switch to set the fan speed.
COOL
°C
Hi
The fan speed is set to “Hi” in
the cooling operation.
By repeatedly pressing the switch, the setting will change sequentially through Hi2, Hi, Me and Lo.
Hi2
Hi
Me
Lo
NOTE
• The fan speed is not displayed during the stoppage. In the case that the fan speed is set during the stoppage, the fan speed indication
is turned ON temporally. It is automatically turned OFF after setting.
• The fan speed can be set for each operation mode. However, the fan speed will be xed at “Lo” in dry operation.
To Next Page
