8.3.2.4 General data
Hardware specications
Item Specications
Power supply 1~ 230V ±10% 50Hz
Consumption 25 W (maximum)
Outer dimensions Width: 143 mm, Depth: 302 mm, Height: 76 mm
Weight 2 kg
Assembling conditions Indoor (in a control panel or desktop)
Ambient temperature 0~40°C
Humidity 20~85% (Without condensation)
Inputs and Outputs restrictions
Item Specications
Analog Inputs AI1~AI8 V: 0~5 V DC, 0.5 A
Digital Inputs DI1~DI8 V: 5V DC, 1.9 A
Outputs: O1~O8 V: 0~24V DC, 1.9A
Communication
Item Specications
Communication with CSNET WEB
Communication line Twisted pair shielded cable, non polarity
Communications system Half-duplex
Communication method Asynchronous
Speed of transmission 9600 Bauds
Length of wiring 1000 m maximum (total length of H-LINK I/O bus)
Maximum number of PC-A1IO 16 x PC-A1IO per O.U. address in a H-LINK / H-LINK II systems
8 Control support devices
PC-A1IO
TCGB0106 rev.0 - 12/2014
720
