6.1.2 System description
6.1.2.1 Distributed system
CSNET WEB is an independent centralised control system which can control an H-LINK communication line. When it is
connected to a system with Packaged units, it can control up to 160 indoor units and 64 outdoor units.
CSNET WEB connects to a Local Area Network or Internet (using a DSL Router) by means of its Ethernet port, so that the
parameters can be adjusted and monitored at a distance.
The internal memory for adjustments to the timer and the units allows CSNET WEB to perform independently after initial
adjustment through a personal computer or similar device.
CSNET WEB does not need a dedicated computer to operate.
The physical device (hardware) of CSNET WEB is called PSC-A160WEB1.
. . .
Air conditioning
unit
Remote PC
(initial adjustment)
H-Link
Ethernet
PSC-A160WEB1
Air conditioning
unit
Air conditioning
unit
NOTE
An initial adjustment is always required.
6.1.2.2 CSNET WEB Network
Up to 4 CSNET WEB servers can be connected to a CSNET WEB client thus forming a CSNET WEB network. This net-
work should be conîš¿gured from Local Computer Conîš¿guration.
6.1.2.3 Based on Java technology
CSNET WEB uses JAVA technology to control and monitor remotely operation of the installation.
If you want the CSNET WEB application to run in a PC, JAVA J2SE Runtime Environment must be installed.
PSC-A160WEB1 is supplied with a CD-ROM to ensure simple installation.
6 Building air conditioning controls
CSNET WEB (PSC-A160WEB1)
TCGB0106 rev.0 - 12/2014
