5.1.2.4 General data
Model PSC-A32MN
Outer Dimension
<W x H x D + (Built-in Part)>
250 × 170 × 25 + 55 (mm)
Net Weight 1.5 kg (approx.)
Installation Location Indoor
Installation Method Wall built-in with JIS switch box for 2 switches (with cover) (JIS C 8340)
Connected Indoor Units (Quantity) 160 (Max.)
Clock Accuracy ± 70 seconds/month (at normal temperature)
Ambient Temperature 5 ~ 35°C
Ambient Humidity 35 ~ 90% (No dew condensation)
Display 8.5” TFT Color Liquid Crystal Display (800 x 480 dots)
Rated Power Supply 1ɸ, AC 100~240V, 50/60Hz
Electrical Power Consumption 30W (Max.)
5.1.2.5 Dimensional data
(Unit: mm)
25
80
55
250
170
Fixing hole
90
198
105
4-4. 6×8
5 Centralised remote controls
PSC-A64GT
TCGB0106 rev.0 - 12/2014
222
