Hitachi PSC-A1T Technical Catalogue

2 Control solutions
Controls compatibility
TCGB0106 rev.0 - 12/2014
3030
2.4.3 Compatibility between each control
PC-ARF PC-ART PC-ARH PC-LH3A PC-LH3B PSC-A64GT PSC-A32MN PSC-A64S PSC-A16RS CSNET WEB CSNET MANAGER HC-A64NET HC-A8MB HC-A64MB HC-A16KNX KNX001 HARC-BX E (A) HARC-BX E (B) PSC-A1T PSC-6RAD PC-A1IO PSC-5HR
Individual
remote
controls
PC-ARF O O O O O O O O O O O O O O O O O O (2) X O O
PC-ART O O O O O O O O O O O O O O O O O O (2) X O O
PC-ARH O O O O O O O O O O O O O O O O O O (2) X O O
PC-LH3A O O O O O O O O O O O O O O O O O O (2) X O O
PC-LH3B O O O O O O O O O O O O O O O O O O (2) X O O
Centralised
remote con-
trols
PSC-A64GT O O O O O O O O O (1) X X X X X X X X (2) O O O
PSC-A32MN O O O O O O O O O (1) X X X X X X X X (2) O O O
PSC-A64S O O O O O O O O O (1) X X X X X X X X O O O O
PSC-A16RS O O O O O O O O O (1) X X X X X X X X O O O O
Building AC
controls
CSNET WEB O O O O O (1) (1) (1) (1) X O X X X X O X X (2) O O O
CSNET MANAGER O O O O O X X X X O O O X X X X X X (2) O O O
HC-A64NET O O O O O X X X X X O X X X X X X X - O O O
Gateways
for building
management
systems
(BMS)
HC-A8MB O O O O O X X X X X X X X X X X X X - O O O
HC-A64MB O O O O O X X X X X X X X X X X X X - O O O
HC-A16KNX O O O O O X X X X X X X X X O X X X - O O O
KNX001 O O O O O X X X X O X X X X X X X X
- O O O
HARC-BX E (A) O O O O O X X X X X X X X X X X O O - X X O
HARC-BX E (B) O O O O O X X X X X X X X X X X O O - X X O
Control
support
devices
PSC-A1T (2) (2) (2) (2) (2) (2) (2) O O (2) (2) - - - - - - - X O O O
PSC-6RAD X X X X X O O O O O O O O O O O X X O O O O
PC-A1IO O O O O O O O O O O O O O O O O X X O O O O
PSC-5HR O O O O O O O O O O O O O O O O O O O O O O
O: 100% Compatible
X: Not compatible
(1): Compatible with limitations.
(2): PSC-A1T is connected directly to central controls. If there are other controls in the same H-LINK II system with timer
settings, ensure that contradictory timer orders are not set.
2.4.4 Compatibility between multiple units of the same control
Next table shows the maximum number of same devices that can be connected on an H-LINK system.
PC-ART PC-ARF PC-ARH PC-LH3A PC-LH3B PSC-A64S PSC-A64GT PSC-A32MN PSC-A16RS CSNET WEB CSNET MANAGER HC-A64NET HC-A8MB HC-A64MB HC-A16KNX KNX001 HARC-BX E (A) HARC-BX E (B) PSC-A1T PSC-6RAD PC-A1IO PSC-5HR
Maximum number
of same devices
nl-1 nl-1 nl-1 nl-1 nl-1 8 8 8 8 1 8 1 1 1 8 1 4 4 1 nl-2 16 4
• nl-1: not limited because it is connected to an indoor unit.
• nl-2: not limited, maximum number dened by H-LINK (145 elements, H-LINK I device).

Hitachi PSC-A1T Specifications

General

Brand	Hitachi
Model	PSC-A1T
Category	Controller
Language	English
