6 Building air conditioning controls
CSNET Manager LT/XT
TCGB0106 rev.0 - 12/2014
515515
6
6.2.2.1 Connectable devices
CSNET Manager Screen can connect up to 8 different devices. The following devices are suitable for connection:
HC-A64NET
ETHERNET
CSNET Manager LT/XT
H-LINK
HC-A64NET
LAN
CSNET Manager is connected to an H-Link installation through an HC-A64NET gateway. CSNET Manager is used to
transmit orders, to store historical data and for time and power consumption management.
NOTE
Do not connect more than one HC-A64NET per H-LINK bus.
CSNET WEB (PSC-A160WEB1)
ETHERNET
CSNET Manager LT/XT
LAN
CSNET WEB
(PSC-A160WEB1)
CSNET Manager is connected to an H-Link installation through CSNET WEB hardware. Its control functions are those in
CSNET WEB, and CSNET manager operates as a graphical interface for the user, like the current TS002
