5.3.2 Installation
5.3.2.1 Installation site selection
Take note of the maximum admissible cable length between units and the control as well as between the units them-
selves, as shown in the following table:
Cable section 0.3 mm
2
≥ 0.75 mm
2
Cable length 30 m 500 m
5.3.2.2 Components list
Unpack the unit and check that:
• The package contains all the components (see next table).
• All components are in perfect condition.
Otherwise, contact the manufacturer.
Name Quant. Comments
Central remote control
1 For controlling system operation.
M4x16L screws
2 For îš¿xing the holding bracket to the wall
Installation and operation manual
1 Installation and operation unit instructions.
NOTE
Bear in mind that the central remote control is divided into two parts:
• Central remote control
• Power source
5 Centralised remote controls
PSC-A64S
TCGB0106 rev.0 - 12/2014
370
