6.1.3.4 General data
Hardware specications
Components Specications
Power supply AC 230 V 1~ ±10% (50Hz)
Consumption 10W (maximum)
External dimensions Width: 240 mm, Depth: 154 mm, Height: 89 mm
Weight 1.4 kg
Installation conditions Indoors (in a control panel, table-top)
Ambient temperature 0~40 °C
Humidity 20~85% (Without condensation)
Specications for communication with the units
Elements Specications
Communication with H-LINK (H-LINK II Compatible)
Communication cable Twin wire, without polarity
Communications system Half-duplex
Communication method Asynchronous
Speed of transmission 9600 Bauds
Length of wiring 1000 m maximum (total length)
Number of units Up to 64 outdoor units and 160 indoor units
Specications for communication with a local area network
Elements Specications
Remote computer
Processor at 1000 MHz, 256 MB RAM, 200 MB free hard disc space. Win-
dows 2000 or higher. Java Runtime Environment Versión 6 Update 3 (*1) or
higher installed (included in the CD-ROM)
NOTE
• (*1) Java(R) is a registered trade mark of Sun Microsystems.
• Remember that H-LINK II has a limit of 200 devices connected. Therefore, in the case of 64 outdoor units connected to the same H-
LINK, only 135 other elements may be connected (including indoor units and control system).
6 Building air conditioning controls
CSNET WEB (PSC-A160WEB1)
TCGB0106 rev.0 - 12/2014
419419
