8.2.2 Installation
8.2.2.1 Installation site selection
Take note of the maximum admissible cable length between units and the control as well as between the units themselves,
as shown in the following table:
Cable section 0.3 mm
2
≥ 0.75 mm
2
Cable length 30 m 500 m
8.2.2.2 Components list
Unpack the unit and check that:
• The package contains all the components (see next table).
• All components are in perfect condition.
Otherwise, contact the manufacturer.
Name Quant. Comments
Adapter
1 With 1.8 m cable
Wiring cover
1 For hiding the wiring
Double face tape
1
110 x 40 x 3 mm
For attaching to the adapter
Connector
2 For H-LINK connection
Tapping screw
2
Ø3.0 x 10mm
For attaching to the wall
Screw
2
Ø3.1 x 16mm
For attaching to the wooden wall
Installation and operation manual
1 Installation and operation unit instructions.
8 Control support devices
PSC-6RAD
TCGB0106 rev.0 - 12/2014
709
