2 Control solutions
Controls compatibility
TCGB0106 rev.0 - 12/2014
2929
2
2.4 Controls compatibility
2.4.1 Compatibility between controls and H-LINK system
Next table shows what sort of H-LINK and what gateway protocol has each device of this technical catalogue.
H-LINK Type
Gateway protocol
H-LINK I H-LINK II
Individual remote controls
PC-ARF O O -
PC-ART O O -
PC-ARH O O -
PC-LH3A O O -
PC-LH3B O O -
Centralised remote controls
PSC-A64GT O O -
PSC-A32MN O O -
PSC-A64S O O -
PSC-A16RS O O -
Building AC controls
CSNET WEB O O Modbus / Fidelio / KNX
CSNET MANAGER O O Modbus / Fidelio
HC-A64NET O O -
Gateways for building
management systems (BMS)
HC-A8MB O O Modbus
HC-A64MB O O Modbus
HC-A16KNX O O KNX
KNX001 O O KNX
HARC-BX E (A) O X LonWorks®
HARC-BX E (B) O X LonWorks®
Control support devices
PSC-A1T O O -
PSC-6RAD O X -
PC-A1IO O O I/O
PSC-5HR O O -
• O: 100% Compatible
• X: Not compatible
Remember that:
• Chiller system is not compatible with package system, this means that chiller and package controls can not be used in
same systems.
• H-LINK II has a limitation of 200 devices.
2.4.2 Compatibility between control groups
The different groups of controls, have a special compatibility between them, as shown in the following table:
Individual re-
mote controls
Central Remote
Controls
Building AC
Central Controls
Computerised
Central Remote
controls (BMS)
Accessories
Individual remote controls O O O O O
Centralised remote controls O O X X O
Building AC controls O X X X O
Gateways for building man-
agement systems (BMS)
O X X X -
Accessories O O O - -
O: 100% Compatible.
X: not compatible with different sort of device.
-: Compatibility depends on the kind of device.
