GENERAL INFORMATION
1-5
GENERAL SPECIFICATIONS
ITEM SPECIFICATIONS
DIMENSIONS Overall length 1,838 mm (72.4 in)
Overall width 668 mm (26.3 in)
Overall height 1,125 mm (44.3 in)
Wheelbase 1,274 mm (50.2 in)
Seat height 740 mm (29.1 in)
Footpeg height 289 mm (11.4 in)
Ground clearance 115 mm (4.5 in)
Curb weight 113 kg (249 lbs)
FRAME Frame type Under bone type
Front suspension Telescopic fork
Front axle travel 80 mm (3.1 in)
Rear suspension Unit swing
Rear axle travel 70 mm (2.8 in)
Front tire size 90/90 – 12M/C 44J
Rear tire size 100/90 – 10M/C 56J
Front tire brand C-922 (CHENG SHIN), MB60(IRC)
Rear tire brand C-922 (CHENG SHIN), MB47(IRC)
Front brake Hydraulic disc brake
Rear brake Mechanical leading trailing
Caster angle 26° 30’
Trail length 74 mm (2.91 in)
Fuel tank capacity 6.5 liter (1.72 US gal, 1.43 lmp gal)
ENGINE Bore and stroke 50.0 x 55.0 mm (1.97 x 2.17 in)
Displacement 108.0 cm
3
(6.59 cu-in)
Compression ratio 11.0: 1
Valve train 2 valve, single chain driven SOHC
Intake valve opens 10° BTDC (at 1 mm lift)
Intake valve closes 25° ABDC (at 1 mm lift)
Exhaust valve opens 35° BBDC (at 1 mm lift)
Exhaust valve closes 5° BTDC (at 1 mm lift)
Lubrication system Forced pressure and wet sump
Oil pump type Trochoid
Cooling system Liquid cooled
Air filtration Viscous paper element
Engine dry weight 27.5 kg (60.6 lbs)
FUEL DELIV-
ERY SYSTEM
Type PGM-FI
Throttle bore 20 mm (0.8 in)
DRIVE TRAIN Clutch system Dry, automatic centrifugal clutch
Drive belt ratio 2.59: 1 – 0.88: 1
Final reduction 9.423 (50/20 x 49/13)
ELECTRICAL Ignition system Full transistorized
Starting system Electric starter motor
Charging system Triple phase output alternator
Regulator/rectifier SCR shorted/triple phase full-wave rectification
Lighting system Battery
