GENERAL INFORMATION
1-9
FRONT WHEEL/SUSPENSION/STEERING SPECIFICATIONS
Unit: mm (in)
REAR WHEEL/SUSPENSION SPECIFICATIONS
Unit: mm (in)
BRAKE SYSTEM SPECIFICATIONS
Unit: mm (in)
ITEM STANDARD SERVICE LIMIT
Minimum tire tread depth – To the indicator
Cold tire
pressure
Driver only 175 kPa (1.75 kgf/cm
2
, 25 psi) –
Driver and passenger 175 kPa (1.75 kgf/cm
2
, 25 psi) –
Axle runout – 0.2 (0.01)
Wheel rim
runout
Radial – 2.0 (0.08)
Axial – 2.0 (0.08)
Fork Spring free length 218.0 (8.58) 213.6 (8.41)
Pipe runout – 0.2 (0.01)
Recommended fluid Fork fluid –
Fluid level 52 (2.0) –
Fluid capacity 89.0 ± 1.0 cm
3
(3.01 ± 0.03 US oz,
3.13 ± 0.04 Imp oz)
–
ITEM STANDARD SERVICE LIMIT
Minimum tire tread depth – To the indicator
Cold tire pressure Driver only 200 kPa (2.00 kgf/cm
2
, 29 psi) –
Driver and passenger 225 kPa (2.25 kgf/cm
2
, 33 psi) –
Wheel rim runout Radial – 2.0 (0.08)
Axial – 2.0 (0.08)
ITEM STANDARD SERVICE LIMIT
Front disc
brake
Specified brake fluid DOT 3 or DOT 4 –
Brake disc thickness 3.3 – 3.7 (0.13 – 0.15) 3.0 (0.12)
Brake disc warpage – 0.30 (0.012)
Master cylinder I.D. 12.700 – 12.743 (0.5000 – 0.5017) 12.755 (0.5022)
Master piston O.D. 12.657 – 12.684 (0.4983 – 0.4994) 12.645 (0.4978)
Caliper cylinder I.D. 27.000 – 27.050 (1.0630 – 1.0650) 27.060 (1.0654)
Caliper piston O.D. 26.918 – 26.968 (1.0598 – 1.0617) 26.91 (1.059)
Rear drum
brake
Brake lever freeplay 10 – 20 (0.4 – 0.8) –
Brake drum I.D. 130.0 – 130.2 (5.12 – 5.13) 131.0 (5.16)
